We focus on magnesium alloy materials for reducing carbon footprint!
Product Details:
Payment & Shipping Terms:
|
SALVAGE: | Scrap Retains A Consistently High Level Of Value | UNIT VOLUME: | Greater Amount Of Finished Magnesium Material Obtained, Pound For Pound |
---|---|---|---|
NONMAGNETIC: | Good For Electrical And Computer Applications | REPID HEAT: | Ideal For A Broad Range Of Operating Temperatures, From 350 Degrees Fahrenheit To -30 Degrees Fahrenheit |
NON-GALLING: | Sound And Rugged Surface, Offering A Low Coefficient Of Friction And Minimum Wear | STRENGTH: | Excellent Strength And Stiffness Per Unit Weight |
CORROSION RESISTANT: | A Wide Variety Of Chemical Treatments Exists For Corrosion Protection, Alteration Of Surface Appearance, And To Provide A Base For Painting. Basic Engineering Precautions Averts Galvanic Corrosion | ALKALI-RESISTANT: | Makes For Easy Cleaning |
WELDING: | Strong Weldments Up To 95% Of Parent Metal, With Minimal Porosity | STABILITY: | No Stress Relief After Machining; No Warps And Is Dent Resistant |
WEIGHT: | Easier Handling Saves Energy And Time | DAMPING: | Absorbs Vibration For Longer Life, While Retaining Dimensional Stability |
Application:: | As The Master Alloy, Magnesium-rare Earth Alloy Can Be Used As The Addictive To Alloys, For The Refining, Hardening And Machinability. | TOOLING: | 4 To 5 Times Greater Tool Life |
FINISH: | Up To 5 Times More Machinable Than Rolled Aluminum | COSTS: | Machine Dry, Without Oil Or Chemicals |
Magnesium forgings AZ80 Magnesium forged billet ZK60 Non-magnetic for electronics
Xi'an XYMCO Magnesium Alloy Materials Co., Ltd. (XYMCO) has manufactured magnesium alloy rod/bar from 1995. We have production capacity with 1250 tonne press, 2500 tonne press and 3600 tonne press in house, our subcontract company has the 8000 tonne press and 10000 tonne press so that we can supply our customers big section extrusions.
Our extrusion capacity is as follows:
Round tube: Max. OD600mmx thickness 125mm
Square tube: 430 x 430mm
Flat bar: 920 x 160mm
U-Shape: 800 x 300mm
Rectangular: 700 x 200mm
Available extrusion alloys:
AZ31B, AZ61A, AZ80A, M1A, ZK60A, Pure Magnesium and Custom alloys
Heat treatment is available as per customer’s application.
Specification:
ASTM B107/B107M-13
GB standard
Existing extrusion tooling for Round Bar (for AZ31, AZ61, AZ80, ZK60, WE43):
Diameter(mm) |
Ø 2.4 |
Ø 3.0 |
Ø 4.0 |
Ø 5.0 |
Ø 6.0 |
Ø 7.75 |
Ø 8.0 |
Ø 10 |
Ø 12 |
Ø 13 |
Ø 14 |
Ø 15 |
Ø 18 |
Ø 20 |
Ø 25 |
Ø 28 |
Ø 30 |
Ø 35 |
Ø 40 |
Ø 45 |
Ø 50 |
Ø 60 |
Ø 70 |
Ø 80 |
Ø 100 |
Ø 120 |
Ø 150 |
Ø 170 |
Ø 210 |
Applications of our extruded products:
The special characteristics of magnesium such as its light weight and damping capacity make it a material that is readily used in several different applications.
Automotive
Engine blocks | Steering column parts | Seat components |
Bed plates | Brake and pedal brackets | Roof panels |
Transmission houses | Airbag retainers | Fuel tank covers |
Transfer cases | Radio frames + heatsinks | Engine hoods |
Head covers | Radio covers | Rear deck lids |
Oil pans | Mirror brackets | Full magnesium doors |
Knee bolsters | Door handles | Wheels |
Steering wheels | Front ends | Radiator supports |
Sport and Leisure
Luggage frames | Suit cases | Tennis rackets |
Bicycle frames | Camping equipment | Snowshoes |
Mountain bike frames | Eyewear frames | Bull floats |
Common applications
Cellular phones | Multi-media housings | Camcorders |
Antenna housing | Camera Housings | Electric shavers |
Loudspeaker frames | Projector frames | Printers |
Laptop Housings | Batteries | Headphones |
Train Seats | Aviation components | Turbine engines |
Truss constructions | Cargo floors | Powertools |
Chain saws | Concrete trowels | Wall saws |
Ladders | Scaffoldings | Shelves |
Xi'an XYMCO Magnesium Alloy Materials Co., Ltd. (XYMCO) QUALITY POLICY
XYMCO is committed to the continuous improvement of our quality system. Our goal is to provide high quality magnesium materials and services that meet customers’ magnesium alloys applicable requirements.
XYMCO COMMITMENT TO QUALITY AND THE ENVIRONMENT
XYMCO’s executive management is committed to providing the resources and leadership required to ensure that the Quality Management System and Environmental Management System function as intended. To fulfill the stated purpose of the organization, XYMCO will:
Ensure a safe workplace and foster a responsible and helpful attitude toward fellow workers.
Address customer requirements, concerns and inquiries in a responsive and professional manner.
Communicate to the entire organization the quality objectives, environmental objectives, and environmental targets of the company.
Instill within the organization a Quality philosophy and Environmental Sensitivity with an emphasis on continuous improvement.
Provide the necessary tools, training and review in all areas including Supervision, Production and sales, to ensure that XYMCO’s Quality Management and Environmental Management objectives and targets are achieved.
Ensure Management conducts regular reviews for continuing suitability of the objectives, policies and procedures contained within the quality program.
XYMCO MISSION STATEMENT
XYMCO will continue improving and maintaining its status as a “premier magnesium materials manufacture and service center” by providing unparalleled quality, responsible environmental stewardship, and exceptional service to our customers. Continuous to do R&D jobs of new magnesium alloy materials to fulfill future market needs.
XYMCO GUIDING PRINCIPLES
Enhance Value by exceeding our customer’s expectations
Respect our customers, fellow employees and suppliers
Respect our planet by reduce carbon footprint through responsible “green” actions
Lead and innovate through the relentless pursuit of excellence
Provide a work environment that fosters pride in our employees
Maintain an atmosphere of learning and teaching that inspires continuous improvement.
Our Services:
1. Small order quantity available
2. Professional engineering team and sales team
3. Payment: T/T & Western Union
4. OEM/ODM Supporttable
5. Free samples provided
6. Competitive price and high quality
FAQ:
1. Q: Are you a factory or trading company?
A: We are direct manufacturer located in Xi'an, Shaanxi province, and have our equipment!
2. Q: Are your products customized?
A: Yes,the products in the website are only the common type or the previous types, we can supply the new products according to your requirements or drawings.
3. I do not know how to use your product ?
Do not worry ! We can supply technical guidance together with products.
4. Q: How can I get some samples?
A: Several samples are freely offered for buidling the business long-term relationships and letting our customers believing the quality of our products.
Contact Person: Mr. Frank Zhang
Tel: 86 189 66935266
